| Details | ![]()
| Remark | |
Product Form | Product Form | Notebook | ||
Dimension | 316*223.8*16.3mm | |||
Weight | <1.35KG | |||
Material | ACD AI alloy, B Plastic | |||
Hinge open angle | 180⁰ | |||
Kensington Lock | Yes | |||
LCD | Screen Size | 16:10 , 14 IPS | ||
Screen Resolution | FHD,1920*1200 | |||
Brightness | 220-300 nits per requirements | |||
Narrow bezel | 3 sides narrow bezel | |||
Battery | Type | Lithium-ion polymer battery | ||
Capacity | 11.55V\4780mAh ,55Wh | MAX 60Wh | ||
Life | about 8~10 Hours | |||
CPU&GPU | CPU Platform | Meteor lake H | ||
Model | Ultra 5-125H/135H; Ultra 7- 155H/165H; Ultra 9-185H/226V/228V/236V/238V/266V/268V/288V | Thermal support TDP 35W | ||
GPU Type | Intel® Arc™ graphics | integration | ||
Storage | RAM | on board LPDDR5 | 4 PCS | |
ROM (eMMC/UFS) | NA | |||
SSD | 1*M.2 2280 PCIe4 | |||
HDD | NA | |||
Camera | Front | 2.0 MP | Without IR camera | |
Camera Switch | Default Camera cover | |||
Speaker | Size | Built-in 4Ω/2W speaker*2 | ||
Cortana | Yes | 2*D-MIC in Camera Module | ||
Fingerprint | Yes | Optional On powerkey | ||
RTC | NA | NA | ||
TPM | Yes | Default FTPM | Support DTPM optional | |
Key | Power Key | On C cover | ||
Key board | Back light | Support | ||
Matrix | US/UK | |||
Touchpad | Type | Multi-touch with 2 buttons and large touchpad | ||
Indicated light | Charge LED | On
with Orange light Off with no light | ||
cap lock | White LED | in KB | ||
Power LED | White LED | |||
Network | WIFI chip model | onboard | ||
Type | Support WiFi 802.11b/g/n/ac/ax | |||
Bluetooth Version | 4.2--5.2 (optional) | follow wifi | ||
4G LTE | NA | |||
Lan | NA | |||
Modern Standby | support | |||
I/O Port | HDMI | 1*Standard HDMI 1.4 | MB side | |
USB Type_A | 1*USB3.2 Gen1 (5GB/s) | |||
USB Type_C | 2*USB3.2 Gen1 (PD/DP/Charger/Data) ; data 5GB/S | |||
Audio Jack | Ø3.5mm Combo | DB side | ||
USB Type_A | 1*USB3.0 | |||
USB Type_A | 1*USB2.0 | |||
Adaptor | standard | Type-C PD 65W/20V, 3.25A | 100W optional | |
Operating System | System | Windows11/Linux |
